Fanvil’s X2C/X2CP/X2P is professional call center IP phones with intuitive, clean
design and rich features at a cost-effective price. Highlights
– Professional IP phone customized for call center □√ 2 SIP Lines, 3-way conference □√ 2.8” (320×240) color-screen (Only X2P)
– 128×48 black-and-white backlit display (X2C/X2CP)
– Support call center headset (RJ9 port, 3.5mm port)
– Electronic Hook Switch (EHS) support for wireless headset
– LED function Keys for Mute/Hold/Call Forwarding/Headset
– Support off-hook/on-hook by pedal switch
– Support LDAP, XML Phonebook
– 10/100Mbps Ethernet, PoE integrated (X2CP/X2P)
– Compatible with major platforms: Asterisk, Broadsoft, 3CX, Metaswitch, Elastix, Avaya etc
Generic
– 2 SIP Lines HD Voice PoE Enabled (X2CP/X2P)
– Headset mode Optional External Power Supply (X2CP and X2P Optional)
Phone Features
– Local Phonebook (500 entries)
– Remote Phonebook (XML/LDAP, 500 entries)
– Call logs (In/out/missed, 600 entries)
– Black/White List Call Filtering
– Screen saver(Only X2P)
– Voice Message Waiting Indication (VMWI)
– Programmable Soft keys Network Time Synchronization Support Plantronics wireless headset (Through Plantronics APD-80 EHS Cable)
– Support Jabra wireless headset (Through Fanvil EHS20 EHS Cable)
– Support Recording (Through Server Recording )
– Action URL / Active URI
– uaCSTA
Call Features
– Call out / Answer / Reject
– Mute / Unmute (Microphone)
– Call Hold / Resume Call Waiting
– Intercom
– Caller ID Display
– Anonymous Call (Hide Caller ID)
– Call Forwarding (Always/Busy/No Answer)
– Call Transfer (Attended/Unattended)
– Call Parking/Pick-up (Depending on server)
– Redial
– Do-Not-Disturb
– Auto-Answering
– Voice Message (On server)
– 3-way Conference Hot Line Hot desking
Audio
– Wideband ADC/DAC 16KHz Sampling
– Narrowband Codec: G.711a/u, G.723.1, G.726-32K, G.729AB Wideband Codec: G.722
Fanvil’s X2C/X2CP/X2P is professional call center IP phones with intuitive, clean
design and rich features at a cost-effective price. Highlights
– Professional IP phone customized for call center □√ 2 SIP Lines, 3-way conference □√ 2.8” (320×240) color-screen (Only X2P)
– 128×48 black-and-white backlit display (X2C/X2CP)
– Support call center headset (RJ9 port, 3.5mm port)
– Electronic Hook Switch (EHS) support for wireless headset
– LED function Keys for Mute/Hold/Call Forwarding/Headset
– Support off-hook/on-hook by pedal switch
– Support LDAP, XML Phonebook
– 10/100Mbps Ethernet, PoE integrated (X2CP/X2P)
– Compatible with major platforms: Asterisk, Broadsoft, 3CX, Metaswitch, Elastix, Avaya etc. Model Screen Network PoE Power adapterX2C 128×48 dot-matrix 10/100Mbps ×√X2CP 128×48 dot-matrix 10/100Mbps √—X2P 2.8” color-screen 10/100Mbps √—X2C/X2CP X2P
– Full-duplex Acoustic Echo Canceller (AEC)
– Voice Activity Detection (VAD) / Comfort Noise Generation (CNG)
/ Background Noise Estimation (BNE) / Noise Reduction (NR)
– Packet Loss Concealment (PLC)
– Dynamic Adaptive Jitter Buffer up to 300ms DTMF: In-band, Out-of-Band – DTMF-Relay(RFC2833) / SIP INFO
