Highlight Features
Rich port types, 48 x 1000 Mbps Ethernet ports,and 4 x 10G optical ports for uplink.
Hardware redundancy, guaranteed service continuity and network connectivity.
VSU virtualization, flexible networking and high performance.
Layer 3 routing control, adaptive to multiple services, efficient and guaranteed data transmission.
Network security policies, real-time monitoring, CPP and NFPP, delivering enhanced network robustness.
SNMP, RMON, Syslog, USB log backup features, CLI, Eweb, telnet and other management modes, simplified and easy network maintenance.
Service port
48 x 10/100/1000 Mbps electrical ports with auto-negotiation, 4 x 1GE/10GE SFP+ ports, 2 x power supply module slots.
Fan module
Two built-in fan modulesFan speed regulating and fault alarms.
Dimensions (W x D x H)
440 mm x 340 mm x 44 mm (17.32 in. x 13.39 in. x 1.73 in.).
Management
1 MGMT port, 1 console port, and 1 USB port, compliant with USB2.0 standard.
Interface surge protection
Power port: 6 kVTelecom port: 10 kV (MGMT port: 4 kV).
